Capabilities

Valley Forge & Bolt Manufacturing Co. is a manufacturer of standard and special fasteners known for its quality products and services. We have designed and developed state-of-the-art patented load indicating fasteners that optimize the integrity of the bolted joint. Consultation and Engineering services are available. We assist customers with the development of special prototype fasteners and have the capability to manufacture fasteners to suit customer’s specifications.

Manufacturing Capabilities

Manufacturing of Special and Standard Fasteners in inch or metric dimensions.

Hot Forging: Diameters from 1/2″ – 3-1/4″  (13mm – 82mm)

Threading:
Roll Threading from 1/2″ – 6-1/2″ diameter (13mm – 165mm)
Cut Threading from 3/8″ – 4-1/2″ diameter (10mm – 114mm)

Machining: CNC Turning and Milling Centers for machining diameters up to 8″ (200mm)

  • N.C. Lathes
  • Cincinnati Machining Center
  • Turret Lathes
  • Bending

  • Cross Drilling
  • Broaching
  • Milling
  • Drilling

  • Slotting
  • Centerless Grinding
  • Welding
  • Tapping


Prototype Specials per Customer Blueprints.

Tightening Equipment (Rental and Sale)

  • Hydraulic Torque Wrenches up to 14,700 ft/lbs
  • Pneumatic Nut Runners up to 7,000 ft/lb

Materials We Work With

  • A-36
  • 1018
  • 1020
  • 1045
  • 4140
  • 4340
  • 8640
  • Stainless
  • 304
  • 309
  • 310
  • 316
  • 321
  • 347
  • 410
  • 416
  • A-286
  • 17-4-PH
  • Inconel 625
  • Inconel 718
  • Alloy 20
  • Aluminum
  • Aluminum Bronze
  • Silicon Bronze
  • Monel 400
  • Monel K-500

Call if your material requirement is not listed.

Specifications

  • ASME
  • ASTM
  • ANSI
  • SAE
  • AREA
  • IFI
  • FF-S-86
  • MIL-B-857
  • MIL-S-1222
  • MIL-I-45208A
  • MIL-I-45662
  • 10-CFR-21
  • DIN
  • JIS
  • SSI
  • BSI
  • AFNOR

Call if your specification requirements are not listed.
